PP, PE, ABS, PVC thick plate extrusion line. The 2000mm broad PP thick plate extrusion line is a newly developed production line, the most advanced and stable production line among similar products.
Features of plastic sheet equipment production line
- PP/PE/ABS/PVC Thick Plate Extrusion Line extrusion equipment: high-efficiency single-screw extruder, with large output and high efficiency, and advanced technologies such as imported temperature control meter and frequency conversion speed regulation, reaching the domestic advanced level. Technology such as melt metering pumps can also be used for products with high precision requirements.
- The hanger-type die head of the pvc sheet production line adopts a unique double-throttle design, which makes the thickness adjustment of the sheet more accurate.
- Temperature control ±1C can precisely control the plasticization process and the thickness and flatness of the plate.
- Three-roll calender adopts horizontal, vertical, or 45-degree inclination type, which can be raised and lowered freely.
- The thickness of the sheet is controlled by screw adjustment and bidirectional adjustment of the pressure wheel to control the thickness of the sheet.
- The screw of PP/PE/PS/ABS/EVA/PET plastic sheet extrusion production line is designed with special mixing function and high plasticizing capacity to ensure that the plastic is melted, the color is uniform, and the extrusion volume is increased. The hanger-type die head adopts a special variable throttle design, which makes the thickness adjustment of the plate more accurate.
- The independently controlled roller temperature control system can precisely control the temperature of the pressing roller to make the plate evenly thick and thin. The precision shearing machine enables precise control of the length of the board.
- PP/PE/ABS/PVC Thick Plate Extrusion Line sheet winder adopts a torque motor, which can adjust the speed and winding tension.
- The winding device of PP/PE/PS/ABS/EVA/PET plastic sheet extrusion production line adopts four-axis, with exceptional torque motor automatic tension control; the speed and winding tension can be adjusted at will to achieve the flatness of sheet winding.
- The screw is designed with particular mixing function and high plasticizing capacity.
- Equipped with an automatic meter counter to set the length of the product.
- Thin adjustment is more precise. The temperature control plus or minus 1℃ can precisely control the plasticization process and the thickness and flatness of the plate.
Application
PP thick plate extrusion line
PP thick plate, is an environmentally-friendly product and is widely applied in chemistry industry, food industry, anti-erosion industry, environmentally-friendly equipments industry, etc. PP thick plate extrusion line of 2000mm width is a newly developed line which is the most advanced and stable line compared with other competitors.
PE thick plate extrusion line
PE plate is widely applied in chemical and electric power industries. HDPE plate, known as engineering plastics, is used in mechanical and chemical equipments as well as ice hockey ring walls.
ABS thick plate extrusion line
ABS thick plate is widely used in the home appliance, electronics, packaging, medical appliance.
PVC thick plate extrusion line
Rigid PVC thick plate is widely used in chemical industry, petrol, electroplating, water purifying equipments, environment-friendly equipments, lamp house and advertisements, etc.
PP/PE/ABS/PVC Thick Plate Extrusion Line Main technical parameter
| Model | Extruder model | Suitable material | Products width(mm) | Products thickness(mm) | Capacity(kg/h) |
| JWS150-2000 | 150/35 | PP、PE、ABS | 1220-1500 | 3-30 | 500 |
| JWS170- 2600 | 170/35 | PP、PE、ABS | 1500-2000 | 3-30 | 700 |
| JWS180/120-3200 | 180/35、 120/33 | PP、 PE、ABS | 2000-2500 | 3-30 | 1200 |
| SJZ80/156- 1500 | SJZ80/156 | PVC | 1220 | 3-30 | 450 |
FAQ
- International Commercial Terms(Incoterms): FOB, CFR, CIF, EXW
- Terms of Payment: LC, T/T
- Average Lead Time: Peak season lead time: 3-6 months, Off season lead time: 1-3 months
- Number of Foreign Trading Staff:>50 People
Yes, We own 5 manufacturing bases and sales center in Shanghai , Suzhou ,Changzhou, Zhou Shan, Dongguan China.
Jwell made the first Chinese screw and barrel in 1978 in brand name Jinhailuo.After more than 40 years development,
JWELL is one of the biggest extrusion machine supplier in China with 300design&test engineer, 3000 employees.
Jwell has become the premier supplier of extrusion lines and reliable business partners. Welcome to drop in us.
Our machines taking the European standards and follow the Germany type of business, we cooperation with
International famous brands Siemens Schneider Flender Omron ABB WEG Falk Fuji etc. Our company continuously
imports over 1000 international first-class high precision processing equipment such as multistage machining centers, CNC lathes and CNC milling machines from Korea, Japan etc. All our processes strictly adhere to CE certification,
IS09001 and 2008 quality management system . And we have 12 months quality warranty time. We testing the
machine performances before each delivery. Jwell service engineers will always be here for anything you needed.
Usually it takes about 1 – 4 months depends on different machinery upon receipt of order advance payment.
Once clear your requirements and determined extrusion line is ideal for you. We will send technical solutions and
Proforma Invoice to you. You can pay via TT bank transfer, LC as you like.
One. We provide both customized extrusion lines and technical solutions. Welcome contact with us for technical
innovation or improvements for your future purchasing plan.
We produce more than 2000 advanced extrusion lines every year world wide.
We can send the small spare parts by air express for urgent matter. And the complete production line by sea
to save the cost. You can either use your own assigned shipping agent or our cooperative forwarder. The nearest
port is China Shanghai, Ningbo port, which is convenient for maritime transportation..
Yes, we support our business partners by pre-after sale service. Jwell has more than 300 technical testing
engineers traveling world wide. Any cases would be responded with prompt solutions. We provide training, testing,
operation and maintenance service for a life time.
